WAGO is a well-known and respected manufacturer of electrical connections, and the WAGO 221-412, 221-415, 221-612, and 221-615 connectors are among their most popular products.
hese connectors offer a range of features and benefits for industrial and commercial applications, and each series has its own specific strengths and design features that make it well-suited for different types of uses.
Below is a comparison of the WAGO 221-412, 221-415, 221-612, and 221-615 connectors.
All four connector products feature a compact design that makes them easy to use and install in tight spaces. The 221-612 and 221-615 connectors have a slightly more compact design than the 221-412 and 221-415 alternatives.
All four connector products are terminal block connectors.
All four series of connector are rated for normal voltage of 450 V and have UL voltage rating of 600V.
The 221-412 and 221-415 connectors are rated for current of up to 32A, while the 221-612 and 221-615 connectors are rated for a current of up to 41A.
The 221-612 and 221-615 connectors are suitable for use in wet environments, while the 221-412 and 221-415 connectors are not.
Below you will find information specifically comparing the wire size suitable for each connector:
This set of connectors is suitable for conductor cross-sections from 0.08 to 2.5 mm2(26 to 14 AWG). The clamp connection mechanism provides a secure and reliable connection for these smaller wire sizes.
This set of connectors is also suitable for conductor cross-sections from 0.08 to 2.5 mm2(26 to 14 AWG). The clamp connectionterminalsmake it aversatilechoice for smaller wire sizes.
This set of connectors is suitable for conductor cross-sections from 0.14 to 4 mm2(24 to 12 AWG). The fastening mechanism allows for quick and easy installation of these larger wire sizes.
This set of connectors is also suitable for conductor cross-sections from 0.14 to 4 mm2(24 to 12 AWG). The clamp style connection makes this series aversatileand convenient choice for larger wire sizes.
In conclusion, WAGO's 221-6 set of connectors offer a high level of reliability and versatility for a wide range of industrial applications. They offer a compact design, making them a great choice for tight spaces. Additionally, the 221-6 section connectors are suitable for a wide range of conductor cross-sections, providing greater flexibility in terms of wire size. With their ability to operate in wet environments, these connectors are an excellent choice for industrial applications where moisture may be present.
In comparison to the 221-412 and 221-415, the 221-612 and 221-615 offer a higher level of performance and reliability, making them ideal for a wide range of industrial applications. With the 221-6 connectors, users can be confident that their electrical connections are secure and dependable, ensuring the safety and efficiency of their systems.
