CEJN 10-807-6604
Product Information
SKU
10-807-6604
Vendor
Cejn
Product Summary
Cejn
Regular price
$594.10 USD
Sale price
Regular price
$514.16 USD
MSRP
Unit price
$594.10 USD
Product Details
Category | Nipples |
Description Class | Female thread |
Connection | 1 5/8"-12 UN - (1 1/4" SAE) |
TLX is a flat-face twist lock coupling for the toughest applications in the construction and demolition segment. This super-duty quick connect coupling is designed to work with the highest surge flows and the toughest pressure impulses. TLX is made from high alloy steels with Zinc-Nickel surface treatment for a long life in the harshest conditions. The Series is available in sizes from ½” to 1½” to cover most applications.The couplings and nipples are also available in 4 other sizes: ½” (Series 507), ¾” (Series 607), 1” (Series 707) and 1 ½” (Series 907)
Flow rate | 400 l/min (88.0 GPM) @ 3bar ΔP ** |
Temperature range | -30°C — +100°C (-22°F — +212°F) |
Material coupling | Steel (Zinc-Nickel) |
Material nipple | Steel (Zinc-Nickel) |
Material seal | Nitrile (NBR) |
Max. working pressure connected | 420 bar (6091 PSI) |
Max. working pressure disconnected | 400 bar (5801 PSI) |
Min. burst pressure connected | 1680 bar (24366 PSI) |
Min. burst pressure disconnected | 1000 bar (14503 PSI) |
Connectability | Connection with residual pressure only limited by operator strength |
Disconnection under pressure | Disconnection with residual pressure in the system is allowed |
