Destaco 235-UB | Horizontal Hold Down Clamp

  • Destaco 235-UB | Horizontal Hold Down Clamp

Product Details

SKU
235-UB
Vendor
Destaco
Inventory

In Stock: 1

$45.31 USD
$43.55 USD MSRP $45.31 USD

Description

235-UB Horizontal Hold-Down Toggle Locking Clamp

  • Model no.: 235-UB
  • Maximum Holding Capacity (N): 3,340
  • Maximum Holding Capacity (lbsf): 750
  • Clamp Arm Length (mm): 105.9
  • Clamp Arm Length (in): 4.170
  • Height Under Clamp Arm (mm): 53.1
  • Height Under Clamp Arm (in): 2.090
  • Clamp Bar Opening (+10°) (degrees): 92
  • Handle Opening (+10°): 70
  • Available: Yes
  • Standard Material: Steel
  • Toggle Lock Plus: No
  • Accommodates Workpiece Variation: No
  • Base Mounting Style: Straight
  • Clamp Arm Style: U-Bar
  • Handle: Horizontal
  • Service Environment; Normal
  • Duty Cycle: 2
  • Product Type: Standard
  • Holding force: 3200: N
  • Angle: 90°
  • Standard equipment: 240208-M
  • Weight (kg): 0.67 (1.48 lb)
Additional Features:
  • Clamp supplied with neoprene spindle
  • Low profile
Application: Welding: Fair/Medium, Assembly: Excellent/High, Checking Fixtures: Excellent/High, Machining: Poor/Low, Wood-Working: Excellent/High, Closures: Excellent/High, Food Processing: Fair/Medium

Specifications

Handle :

Horizonal

Duty Cycle :

2

Product Type :

Standard

Weight (lb) :

1.48

Product Series :

235

Clamp Arm Style :

U-Bar

Flanged Washers :

235106

DistributorGroup :

Workholding (Manual, Power and Hydraulic Clamps)

Product Function :

Clamping

Spindle Assembly :

240208-M

Toggle Lock Plus :

No

Standard Material :

Steel

Base Mounting Style :

Straight

Service Environment :

Normal

Application - Welding :

Fair/Medium

Clamp Arm Length (in) :

4.17

Application - Assembly :

Excellent/High

Application - Closures :

Excellent/High

Handle Opening (+10°) :

70

Application - Machining :

Poor/Low

Application - Wood-Working :

Excellent/High

Height Under Clamp Arm (in) :

2.09

Application - Food Processing :

Fair/Medium

Maximum Holding Capacity (lbf) :

750

Accomodates Workpiece Variation :

No

Application - Checking Fixtures :

Excellent/High

Clamp Bar Opening (+10°) (degrees) :

92
