Output current IëÀ: 10 A at 24 VDC and 110 - 240 VAC 8 A at 24 VDC and 100 - 240 VAC
Standards/specifications: EN 60950, EN 61204-3, EN 60335, UL 60950*, UL 508*, (*pending)
External fuse: Circuit breakers B6, B10; An external DC fuse is required for the DC input voltage
Overload behavior: Constant power (in overload range: 1.05 - 1.4 x IëÀ); shutdown and automatic restart in the event of a short circuit

- Switched-mode power supply
- Protection class I
- Natural convection cooling when horizontally mounted
- Enclosed for use in control cabinets
- Suitable for both parallel and series operation
- Electrically isolated output voltage (SELV) per EN 60950-1/UL 60950-1
- DIN-35 rail mountable in different positions
- Installation width (as delivered): 70 mm
- Direct installation on mounting plate via cable grip
