Wago 859-303 Switching Relay Terminal Block Miniature

Product images are for illustrative purposes only and may differ from the actual product.

Product Information

SKU
859-303
Vendor
Wago

Product Summary

Wago

$26.21 USD
$28.08 USD MSRP $26.21 USD
Shipping calculated at checkout.
Product Details

Wago 859-303 / RoHS Compliant / SPST, 12 VDC, 5 A, DIN Rail

  • Conformity marking CE
  • Pollution degree 2
  • Rated voltage [V] 250 V
  • Rated impulse voltage [kV] 4 kV
  • Pull-in time (typ.) [ms] 8 ms
  • Mechanical life 5 x 106 switching operations
  • Drop-out time (typ.) [ms] 4 ms
  • Nominal input current IN 17 mA
  • Operating power < 320mW
  • Input voltage range VN -15 % ... +20 %
  • Maximum switching voltage 250 VAC
  • Maximum switching power (resistive) 1250 VA AC ; DC see load limit curve
  • Recommended minimum load 10 VDC / 10 mA, 24 VDC / 1 mA
  • Maximum switching load with load/without load 6 min-1 / 180 min-1
  • Bounce time (typ) [ms] 5 ms
  • Nominal operating mode continuous duty
  • Dielectric strength, contact-coil (AC, 1 min) [kVrms 4 kVrms
  • Dielectric strength contact-coil (1.2/50 åµs) [kV] 6 kV
  • Dielectric strength, open contact [kV] 1 kV
  • Dielectric strength open contact (AC, 1 min) [kVrms 1 kVrms
  • Mechanical life at max. load (resistance) 5 x 104 switching operations
  • Nominal input voltage UN 12 VDC
  • Maximum continuous current 5 A
  • Maximum make current 4s (AC), 10A
  • Electrical life 5 x 104 switching operations
  • Connection technology CAGE CLAMP®
  • Type of wiring Front-entry wiring
  • Contact material AgSnO2
  • Fire load [MJ] 0.313
  • Storage temperature -40 °C ... +70 °C
  • Type of mounting DIN-35 x 15 carrier rail
  • Ambient operating temperature at VN -25 °C ... +50 °C
  • Ambient operating temperature for UL () -25 °C ... +40 °C
