Product Design Features:
Case: Black Pocan
Case Fill: Dry, field fillable Ingress
Measuring System 316L Case Filling For Vibration
Ring: Threaded Black Pocan
Restrictor: Stainless Steel, Orifice 0.6mm (0.024 inches)
Wetted Part: Copper Alloy
Protection: IP 65
Window: Clear Plastic, Acrylic
Pointer: Black Aluminum, adjustable
Dial: White Aluminum, stop pin on dial: at 6 o'clock
Accuracy: + 0.5% of span ASME B40.100 Grade 2A
Steady Working pressure: full-scale value
Fluctuating Working pressure: 0.9 x full scale value
Short time Working pressure: 1.5 x full scale value
Ambient Operating temperature: Dry -40°F to +150°F (-40°C to +65°C)
Medium Operating Temperature: +212°F (+100°C) maximum

Applications: For applications with high dynamic pressure pulsations or vibration a liquid filled case and socket restrictor are available - Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system
Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
