CEJN 10-116-1202

Product images are for illustrative purposes only and may differ from the actual product.

Product Information

SKU
10-116-1202
Vendor
Cejn
Inventory

Product Summary

Cejn

Regular price $93.48 USD
Sale price Regular price $93.48 USD MSRP Unit price $93.48 USD
Shipping calculated at checkout.
Product Details

Category Couplings
Description Class Female thread
Remark -
Connection G 1/4"
Length 61.3 mm
Diameter 28 mm
Hexagon 24 mm
Rec. torque (Nm) 40-50 Nm
Rec. seal. method CMS*

The 116 series of hydraulic quick connect couplings for ultra high pressure are easy to handle, safe and reliable. The quick couplers are available in both standard and flat-face designs. Series 116 are non-drip couplings with clean connection and disconnection protecting both the environment and circuit integrity. The safety lock comes as standard and it adds an extra layer of safety by eliminating any risks of accidental disconnections. The high performance and robust design with small outer dimensions, makes it a suitable option in many different applications. Additionally, a 90° swivel connection is available for use in confined areas. The couplings and nipples are available in stainless steel for use in corrosive environments. Plastic dust caps come as standard for both the couplings and nipples. These extend the lifetime of couplings, nipples and the entire hydraulic system. Aluminum dust caps are also available upon request.Applications: Hydraulic bolt tensioning, Test benches, Cylinders, Bearing pullers

Nominal flow diameter 2.5 mm (0.1")
Flow capacity 6.0 l/min (1.3 GPM UK)
Max. working pressure 150 MPa
Min. burst pressure 300 MPa
Temperature range -30°C — +100°C (-22°F — +212°F)
Material coupling Hardened, zinc chromate plated steel
Material nipple Hardened, zinc chromate plated steel
Material seal Nitrile (NBR) other sealing material on request
