Kinequip CM30P7-1 | Mag Drive Centrifugal Circulating Pump
Product Information
Product Summary
Kinequip
Kinequip CM30P7-1 | 12V Circulation Pump
The CM30P7-1 Mag Drive Centrifugal Circulating Pump is a powerful, efficient and reliable 12V circulation pump with a capacity of 5.3 GPM, and is capable of running dry for up to 30 minutes. It comes with a separate universal bracket for flat surfaces, and is compatible with either 5/8" or 3/4" hose. Its pump body and shaft are both constructed with PPA, thermoplastic and Stainless Steel, and it has a maximum liquid temperature of 212°F and a minimum liquid temperature of -40°F, with a system pressure of 2.5 bar max (36 psi).
Features:
Capacity | 5.3 GPM
Dry running | 30 minutes max
Impeller | PPA, Thermoplastic
Input Power | 27W Max
Length | 6.97"
Maximum Liquid Temp | 212° F
Minimum Liquid Temp | -40° F
Mounting | Separate universal bracket for flat surfaces
Port size | 5/8" or 3/4" hose
Pump Body | PPA, Thermoplastic
Shaft | Stainless Steel
System Pressure | 2.5 bar max (36 psi)
Voltage | 12
Width | 2.68in
Height | 3.35in
