Product Design Features:
Case: 304 Stainless Steel
Ring: Polished Stainless Steel
Case surface: Bare case
Material pressure element: Measuring System 316L
Wetted Part: 316 Stainless Steel
Window: Laminated Safety Glass
Pointer: Black Aluminum, adjustable, Set / Drag
Dial: White Aluminum
Accuracy: + 1% of span ASME B40.100 Grade 1A
Steady Working pressure: Full-scale value
Fluctuating Working pressure: 0.9 x full scale value
Short time Working pressure: 1.3 x full scale value
Ambient Operating temperature: Dry -40°F to +140°F (-40°C to +60°C)
Medium Operating Temperature: Dry +392°F (+200°C) maximum

Applications (232.50 SP09.03): Option for robust process pressure measuring instruments models 23x.50 in the nominal sizes 100 and 160 - Monitoring of critical process pressures regarding the set limit values - Tamper-proof detection for when a preset pressure value is exceeded

Applications (232.50 PM02.02):With liquid-filled case for applications with high dynamic pressure pulsations or vibration - Suitable for corrosive environments and gaseous or liquid media that will not obstruct the pressure system - Process industry: chemical/petrochemical, power stations, mining, on and offshore, environmental technology, mechanical engineering and plant construction
