Product Design Features:
Wetted Part: Copper Alloy (Socket Brass)
Window: Snap-In Polycarbonate
Pointer: Black Aluminum
Dial: White Aluminum
Accuracy: + 3/2/3% of span / ASME B40.100 Grade B
Steady Working Pressure: 3/4 of full scale value
Fluctuating Working Pressure: 2/3 of full scale value
Short Working Pressure: Full scale value
Ambient Operating Temperature: -40°F to 140°F (-40°C to 60°C)
Media Operating Temperature: 140°F (+60°C) maximum

Applications: Hydraulic and pneumatic systems - Pumps, compressors, water systems, regulators - Suitable for fluid medium which does not clog connection port or corrode copper alloy
